Multi-Stage Volute Casing Pattern
Industry: Pump & Hydraulic Engineering
Material Used: Aluminium 6061-T6 (VMC Machined)
Description: Engineered intricate 5-piece split core box and pattern equipment with precision loose pieces to enable smooth internal hydraulic flow passages.
4-Cylinder Engine Block Match Plate
Industry: Automotive & Commercial Vehicles
Material Used: High Density CI & Aluminium Alloy
Description: Manufactured high-speed automatic DISA line matchplate pattern equipment producing over 150 flasks/hour with zero parting line flash.
24" High Pressure Valve Body Tooling
Industry: Industrial Valves & Flow Control
Material Used: Seasoned Teak Wood with PU Finish
Description: Large-scale wooden pattern and core box engineered with exact shrinkage allowance for alloy steel castings under 100 bar pressure test.
Jaw Crusher Frame & Swing Jaw Pattern
Industry: Mining & Heavy Machinery
Material Used: Laminated Seasoned Pine Wood
Description: Reinforced 3.5-meter long wooden pattern designed to withstand aggressive sand ramming for manganese steel crusher castings.
Tractor Transmission Gearbox Pattern
Industry: Agriculture & Farm Equipment
Material Used: CNC Milled Aluminium Tooling
Description: Complex multi-cavity cold box core assembly and matchplate pattern equipment for ductile iron tractor housings.
Locomotive Coupler Yoke Tooling
Industry: Railway & Locomotive Equipment
Material Used: Cast Iron Pattern Plates & Steel Vents
Description: Heavy-duty metal pattern tooling engineered to withstand high-volume no-bake sand moulding for railway steel castings.
